Cortizo Cor Vision vs Cor Vision Plus: Which to Specify

Cortizo Cor Vision and Cor Vision Plus are the two slim aluminium sliding doors in Cortizo's residential range, and the difference comes down to scale. Cor Vision has the slimmer 20mm central junction and suits most extension and patio openings, with sashes up to 2.2m wide by 3m high in double glazing. Cor Vision Plus has a 25mm junction but takes sashes up to 4m by 4m, triple glazing, motorised operation and up to 94% glass. We fabricate both in our Uxbridge workshop and install them ourselves; see the range on our Cortizo sliding doors page or request a free quote.
This guide sets the two Cor Vision systems side by side: sightlines, sash sizes, glazing, thermal figures, security, and the simple aperture test we use at survey to decide between them. We install both across Buckinghamshire, Berkshire, Oxfordshire, Surrey, Hampshire, Hertfordshire and West London, so the comparison reflects the openings we actually quote rather than brochure copy.
Cor Vision vs Cor Vision Plus at a Glance
| Cortizo Cor Vision | Cortizo Cor Vision Plus | |
|---|---|---|
| Central junction | 20mm (the slimmer of the two) | 25mm |
| Maximum sash | 2.2m wide x 3m high (catalogue) | 4m x 4m |
| Maximum sash weight | 320kg | 400kg manual, 700kg motorised |
| Glazing | 26–30mm, double glazing only | 36–56mm, double or triple |
| Thermal (Uw) | from 1.3 W/m²K | from 0.9 W/m²K |
| Glass area | slim frames throughout | up to 94% glass |
| PAS 24 | can be specified to PAS 24 | not PAS 24 compatible |
| Operation | standard in-line slider | standard in-line slider, motorised option |
Both share Cortizo's hardware family, multi-point locking, anti-lift protection on the track and the full RAL colour palette. Both carry our 10-year CPA insurance-backed guarantee, and we are FENSA registered.
What Is Cortizo Cor Vision?
Cortizo Cor Vision is a slim aluminium in-line sliding door for homes. Its defining feature is the 20mm central junction, the vertical line where the two sliding leaves meet when closed. That is the slimmest junction of the Cortizo sliders we fit, so a closed Cor Vision door reads as a near-continuous sheet of glass rather than a door with a heavy mullion in the middle.
Cortizo's catalogue gives a maximum sash of 2.2m wide by 3m high at up to 320kg per panel. Cortizo's technical file quotes a wider 2.5m sash, so for any leaf wider than 2.2m we confirm the size with our profile supplier before we quote. Cor Vision takes 26–30mm double glazed units only, and Cortizo quotes Uw from 1.3 W/m²K, inside the Building Regulations limits in England for glazed doors (1.4 W/m²K or DSER band C for doors more than 60% glazed).
That combination covers the majority of UK rear extensions, kitchen openings and patio doors: a two or three panel door across a typical opening, slim sightlines and a sensible thermal figure.
What Is Cortizo Cor Vision Plus?
Cortizo Cor Vision Plus is the larger-format version, built for big openings and heavy glass. The central junction grows to 25mm, only 5mm wider than Cor Vision, but everything else scales up:
- Sashes up to 4m x 4m
- Up to 400kg per sash manually, or 700kg motorised
- Glazing from 36mm to 56mm, enough for triple glazing and thick acoustic laminated units
- Uw from 0.9 W/m²K, the better thermal figure of the two
- Up to 94% glass, so even very wide doors read as a glass wall
Cortizo also offers Cor Vision Plus in corner and pocket configurations, where the sashes meet at a corner with no post or slide into the wall. Whether a corner or pocket detail suits your opening depends on the structure around it, and we confirm it at survey.
Cor Vision vs Cor Vision Plus: Sightlines
The central junction is the line you see every day, so it is often the first thing buyers ask about. Cor Vision's 20mm junction is the slimmer of the two. Cor Vision Plus at 25mm is a small step wider, and on a large door with up to 94% glass the difference is hard to see from inside the room.
In practice, sightlines rarely decide between the two on their own. If your opening fits Cor Vision's sash limits, you get the slimmer junction and a lighter specification. If it does not, Cor Vision Plus still gives an exceptionally clean, glass-led look at a much larger size.
Sash Size: The Deciding Difference
Size is the single biggest practical difference, and it is the test we apply first:
- Each leaf 2.2m wide x 3m high or smaller, double glazed, 320kg or less: Cor Vision.
- Any leaf wider than 2.2m or taller than 3m: Cor Vision Plus, which goes to 4m x 4m.
- Heavy glass: triple glazing or thick acoustic laminated units push sash weight up quickly, and Cor Vision Plus takes 400kg manually or 700kg motorised.
Total opening width depends on how many panels you choose and how many are fixed. Your surveyor measures the structural opening and sets the panel layout, and any width close to the limits is confirmed before we quote.
Glazing and Thermal Performance
Cor Vision is double glazed only, with 26–30mm units and Uw from 1.3 W/m²K. Cor Vision Plus takes 36–56mm units, so it can be triple glazed, and Cortizo quotes Uw from 0.9 W/m²K.
Both figures are Cortizo's best-case values. The Uw for your door is calculated for your sizes and glass at quote stage, and every door we fit meets the Building Regulations requirement for its job. If you want the best thermal figure across a large opening, Cor Vision Plus is the stronger choice; if you want the slimmer look at normal sizes, Cor Vision is comfortably compliant.
Security and PAS 24
This is the point that changes the answer for some buyers. Cor Vision can be specified to PAS 24. Cor Vision Plus is not PAS 24 compatible.
Where a new-build specification, an insurer or a planning condition calls for PAS 24, Cor Vision is the Cortizo slider to choose, or we look at another system such as the Cortizo 4700 Sliding. Both Cor Vision systems share the same everyday security hardware:
- Multi-point locking
- Anti-lift devices on the running track, so the leaf cannot be lifted out from outside
- Internally beaded glazing
- Toughened safety glass in the locations Approved Document K requires
- A high-security anti-snap cylinder
Secured by Design configurations are available on Cor Vision where a project needs them. Our accreditations page covers our own certifications.
Standard Sliders, Not Lift-and-Slide
Both Cor Vision systems are standard in-line sliding doors: the leaf rolls along the track and the handle operates the lock without lifting the sash. Cortizo's lift-and-slide option in our range is the lift-and-slide version of the Cortizo 4700 Sliding, where the handle lifts the leaf off its seal before it moves. That system has a 47mm interlock and sashes up to 2.5m x 3m at up to 300kg in its lift-and-slide version. See our Cortizo lift-and-slide page.
The Cortizo 4900 Sliding HI is also an in-line slider, with a 35mm junction. Our Cortizo 4700 vs 4900 comparison covers both.
Cor Vision Plus vs Schuco Sliding Doors
Buyers comparing premium sliders often look at Schuco as well. The Schuco ASS 77 PD Panorama is a lift-and-slide system with sashes up to 500kg, and the Schuco ASS 70.HI Slimline takes up to 400kg manually. Cor Vision Plus answers with a larger maximum sash, a 25mm junction and up to 94% glass; Schuco answers with lift-and-slide operation and its own engineering approach. Which suits you depends on the opening, the glass and how you want the door to operate. Our Cortizo vs Schuco guide compares the two brands across their ranges.
Colour and Finish
Both systems are powder coated in any RAL colour, with dual colour (a different shade inside and out) available. Anthracite Grey, black, white and bronze tones are the most requested. The finish is applied to the profile before we fabricate the door, so frames, sashes and track match.
When to Choose Cor Vision
- Openings where each leaf is 2.2m wide by 3m high or smaller
- Double glazing is all you need
- You want the slimmest junction of the Cortizo sliders we fit (20mm)
- The project needs PAS 24
- Rear extensions and patio replacements where Plus capacity would go unused
When to Choose Cor Vision Plus
- Any leaf wider than 2.2m or taller than 3m, up to 4m x 4m
- Triple glazing or thick acoustic glass
- Sashes heavier than 320kg, or motorised operation
- The best thermal figure (Uw from 0.9 W/m²K) and the most glass (up to 94%)
- Corner or pocket details, confirmed at survey
- PAS 24 is not required
Cor Vision Pricing
We do not publish fixed prices for Cortizo sliding doors, because the cost depends on sash size, panel count, glazing, colour, threshold detail and any structural work to the opening. Cor Vision Plus costs more than Cor Vision for the same opening because of its larger profiles and glass capacity. For typical installed price ranges, read our Cortizo Cor Vision sliding doors cost guide and our aluminium sliding doors cost guide. If you are in the county, our Berkshire aluminium doors page covers local survey and installation.
Vitrum Solutions and Cortizo
Vitrum Solutions is a Cortizo manufacturer, fabricator and installer. Cortizo supplies the profile and we cut, machine and assemble every Cor Vision door in our Uxbridge workshop, then fit it with our own teams. Because we fit both tiers, we specify the one your opening needs rather than defaulting to the bigger system. Browse the Cortizo brand hub for the full range, including bi-folds, windows and Millennium Plus entrance doors.
Frequently Asked Questions
What is the difference between Cortizo Cor Vision and Cor Vision Plus?
Cor Vision has a 20mm central junction, sashes up to 2.2m wide by 3m high at 320kg, 26–30mm double glazing and Uw from 1.3 W/m²K, and it can be specified to PAS 24. Cor Vision Plus has a 25mm junction, sashes up to 4m by 4m at 400kg manual or 700kg motorised, 36–56mm glazing including triple, Uw from 0.9 W/m²K and up to 94% glass, but it is not PAS 24 compatible. Choose by opening size, glass and security requirement.
Which has the slimmer frame, Cor Vision or Cor Vision Plus?
Cor Vision has the slimmer central junction at 20mm, against 25mm on Cor Vision Plus. On a large door the Plus still reads as a glass wall because up to 94% of its area is glass, so the 5mm difference is rarely the deciding factor. Sash size, glass and PAS 24 usually decide first.
Can I have triple glazing on a Cor Vision slider?
Only on Cor Vision Plus, which takes glazing from 36mm to 56mm thick, enough for triple glazed and thick acoustic laminated units. Cor Vision takes 26–30mm units and is double glazed only. If your project needs triple glazing on the slider, Cor Vision Plus is the system.
Is Cor Vision Plus PAS 24 certified?
No. Cor Vision Plus is not PAS 24 compatible. Where a specification, insurer or planning condition requires PAS 24, Cor Vision can be specified to PAS 24, and the Cortizo 4700 Sliding is another option we fit. Both Cor Vision systems include multi-point locking, anti-lift track protection, internally beaded glazing and toughened safety glass.
Is Cor Vision a lift-and-slide door?
No. Cor Vision and Cor Vision Plus are both standard in-line sliders, so the leaf rolls on its track without being lifted. Cor Vision Plus still moves sashes up to 400kg manually and 700kg motorised. For a Cortizo lift-and-slide door, we fit the lift-and-slide version of the Cortizo 4700 Sliding; see our Cortizo lift-and-slide page.
What is the biggest opening a Cor Vision slider can fill?
It depends on how many panels you choose and how many are fixed. Cor Vision takes sashes up to 2.2m wide by 3m high in its catalogue sizes, so it suits most two and three panel openings. Cor Vision Plus takes sashes up to 4m by 4m, so a multi-panel Plus door can span a very wide opening. Your surveyor measures the structural opening and confirms the panel layout and sizes before we quote.
Where is Cor Vision made and how long does it take?
Cortizo extrudes the Cor Vision profile in Spain, and Vitrum Solutions fabricates each finished door to order in our Uxbridge workshop. There is no off-the-shelf stock, so the lead time runs from order and depends on profile availability, colour, glass and any motorised hardware. We confirm the timescale on your quote, and your surveyor measures every opening before fabrication starts.
Getting a Quote
Request a free quote and we can price both Cor Vision systems for your opening, so you can compare them side by side. For more on Cortizo, read our Cortizo sliding doors review, our Cortizo aluminium windows review and our Cortizo Bi-Fold vs Bi-fold Plus Door comparison.
